Chapter 15 – SIM TOOLKIT
Multi-Tech Systems, Inc. CDMA Wireless AT Commands - PN S000294C 115
Error Codes
+CME ERROR: 3 Operation not allowed . This error is returned when a wrong parameter is entered.
Example:
AT+CMEE=1 Enable the reporting of mobile equipment errors
OK
AT+WIND=15
Set indications
OK
AT+CPAS
Query ME Status
+CPAS: 0 ME is ready.
OK
AT+STSF=?
Test command SIM ToolKit Set Facilities
+STSF: (0-2), (160060C01F . 5FFFFFFF7F),(1-255)
OK
AT+STSF?
+STSF:
0,”160060C000”,3 No activation of SIM ToolKit functionality
OK
AT+STSF=2,”5FFFFFFF7F”
Set all SIM ToolKit facilities (class 3).
OK
AT+STSF=3
Syntax Error
+CME ERROR: 3
AT+STSF=1
Activation of SIM ToolKit functionality
OK
AT+CFUN=1
Reboot Software.
OK
AT+CPIN?
Is the ME requiring a password?
+CPIN: SIM PIN Yes, SIM PIN required
AT+CPIN=0000
OK PIN Ok
+WIND:
4 Init phase is complete
AT+STSF?
+STSF:
1,”5FFFFFFF7F”,3 SIM ToolKit functionality activated with all facilities
OK
SIM ToolKit Indication (+STIN)
Unsolicited Result:
In order to allow the customer application to identify the pro-active command sent via SIM ToolKit, a
mechanism of unsolicited SIM ToolKit indications (+STIN) is implemented.
Syntax:
+STIN:
Option:
0: Indicates that a .Setup Menu. Pro-active command has been sent from the SIM.
1: Indicates that a .Display Text. Pro-active command has been sent from the SIM.
2: Indicates that a .Get Inkey. Pro-active command has been sent from the SIM.
3: Indicates that a .Get Input. Pro-active command has been sent from the SIM.
4: Indicates that a .Setup Call. Pro-active command has been sent from the SIM.
5: Indicates that a .Play Tone. Pro-active command has been sent from the SIM. (*)
6: Indicates that a .Sel Item. Pro-active command has been sent from the SIM.
7: Indicates that a .Refresh. pro-active command has been sent from the SIM. (*)
9: Indicates that a .Send SMS. Pro-active command has been sent from the SIM. (*)
11 : Indicates that a SETUP EVENT LIST. Pro-active command has been sent from the
SIM.
98 : Indicates the timeout when no response from user.
99: Indicates that a .End Session. Has been sent from the SIM.
(*) if the automatic response parameter is activated, this indication is followed by the
corresponding +STGI response.
