Page 72
Replacement Parts List
CF-52AJYZDZM
NRP: Non Reusable Parts
PART NO.
DESCRIPTION
Q'TY
E1
DL3U11616AAA
PCB, MAIN HIGH
RTL
1
E2
DL3U21616AAA
PCB, AUDIO
RTL
1
E3
DL3U31616AAA
PCB, SERIAL
RTL
1
E4
DL3U41616AAA
PCB, TOUCH PAD
RTL
1
E5
DL3U51616AAA
PCB, SW LED MDC
RTL
1
E6
DL3U61616AAA
PCB, SD
RTL
1
E7
DL3U71616AAA
PCB, PWR BATTERY LED
RTL
1
E8
DL3U81616AAA
PCB, SC RELAY
RTL
1
E9
DL3U91616AAA
PCB, WWAN
RTL
1
E10
DL3UA1616AAA
PCB, BIOS HIGH
RTL
1
E11
DL3UP1621AAA
PCB, BT UNIT
RTL
1
E15
DL3U11622AAA
ANTENNA PWB R
RTL
1
E15-1
DFJS1098ZB
WLAN ANTENNA CABLE R
1
E15-2
DFJS1100ZA
WWAN ANTENNA CABLE R
1
E16
DL3U21622AAA
ANTENNA PWB L
RTL
1
E16-1
DFJS1097ZB
WLAN ANTENNA CABLE L
1
E16-2
DFJS1099ZB
WWAN ANTENNA CABLE L
1
E17
N5ZZ00000128
1GB DDR2-667 SO-DIMM
1
E18
DFJK9012YA
FFC, PAD
1
E19
DFJK9014YA
FFC, SC FS
1
E20
DFJK9024ZB
FFC, CLICK
1
E21
DFJK9025ZA
FFC SD
1
E22
DFJS1078ZA
SW LED I/O CABLE
1
E23
DFJS1079ZA
AUDIO LED SW CABLE
1
E24
DFJS1080ZA
BLUETOOTH CABLE
1
E25
DFJS1081ZB
LAN CABLE
1
E26
DFJS1082ZB
MODEM CABLE
1
E27
DFJS1095ZB
CABLE ANT RELAY WLAN L
1
E28
DFJS1096ZC
RELAY WLAN ANTENNA CABLE R
1
E29
DFJS1111ZB
SPEAKER CABLE-L
1
E30
DFJS1112ZB
SPEAKER CABLE-R
1
E31
DFUP1641ZA
FPC
1
E32
L0AA02A00080
SPEAKER
2
E33
N2EAYYY00003
PAD
1
E34
S N5HAZ0000016
MODEM
1
E35
S N0GF1J000011
INVERTER
NRP
1
E36
K1NB94B00002
EX/PC CARD EJECTOR
1
E37
S N5HZC0000031
WIRELESS LAN MODULE
1
E38
DFWP0146ZA
BATTERY FPC ASS'Y
1
E39
DFWP0147ZB
KBD SD RELAY FPC ASS'Y
1
E40
L5EDDYY00060
LCD HIGH
1
E41
DFJS1077YA
INVERTER CABLE
1
E42
DFJS1128ZA
LCD CABLE
1
E201
N2ABZY000035
KEYBOARD VISTA US
1
E202
S N3CAYYY00021
HDD
1
A1
S DFQW5048ZBT
MANUAL(CF-52MK1 USA)
1
A2
S K2CG3DR00004
AC CORD
1
A3
S CF-AA1683AMA
AC ADAPTOR
1
A4
S CGR-B/982AE
LITHIUM ION BATTERY PACK
1
A5
DFJS1070ZA
MODEM CABLE
1
P1
DFPN0851ZAT
CUSHION T
2
P2
DFPN0852ZAT
CUSHION B
2
P3
DFPE0873ZAT
BATTERY HOLDER
1
P4
DFPE0874ZBT
MANUAL HOLDER
1
Packing Material
Note : Important Safety Notice
Components identified by mark have special characteristics important for safety.
When replacing any of these components, use only manufacturer's specified parts.
Main Block Unit
Accessories
REF. NO and AREA
!
