Matsushita CF-52AJYZDZM - Manual (Page 7)

1. Specifications
1-1
This page provides the specifications for the basic model CF-52AJCBDBM / CF-52BJCBZBM / CF-52AJCHDBM / CF-
52CCABXBM / CF-52DCABZBM. The model number is different according to the unit configuration.
To check the model number:
Check the bottom of the computer or the box the computer came in at the time of purchase.
To check CPU speed, memory size and the hard disk drive (HDD) size:
Run the Setup Utility and select [Information] menu.
[CPU Speed]: CPU speed, [System Memory]: Memory size, [Hard Disk]: Hard disk drive size
Main Specifications
Model No. CF-52AJCBDBM / CF-52BJCBZBM /
CF-52AJCHDBM CF-52CCABXBM / CF-52DCABZBM
CPU
Intel
®
Core™ 2 Duo Processor T7300
(2.0 GHz, 4 MB
*1
L2 cache, 800 MHz FSB)
Intel
®
Core™ 2 Duo Processor T7100
(1.8 GHz, 2 MB
*1
L2 cache, 800 MHz FSB)
Chipset
Mobile Intel
®
PM965 Express Chipsets Mobile Intel
®
GM965 Express Chipsets
Memory
*1*2 1024 MB (4096 MB Max.)
Video Memory
*1 512 MB
UMA (384 MB Max.)
*3
Hard Disk Drive
*4 120 GB 80 GB
Display Method 15.4 WUXGA type (TFT) 15.4 WXGA type (TFT)
Internal LCD
*5 65,536/16,777,216 colors
(800
× 600 dots/1024 × 768 dots/1280 × 768
dots/1600 × 1200 dots/1920 × 1080 dots/
1920 × 1200 dots)
65,536/16,777,216 colors
(800
× 600 dots/1024 × 768 dots/1280 × 768
dots/1280 × 800 dots)
External Display
*6 65,536/16,777,216 colors (800 × 600 dots/1024 × 768 dots/1280 × 768 dots/1280 × 1024 dots/
1600 × 1200 dots/1920 × 1080 dots/1920 × 1200 dots/2048 × 1536 dots)
LAN IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T
Modem Data: 56 kbps (V.92) FAX: 14.4 kbps
Sound
WAVE and MIDI playback, Stereo speaker, Intel
®
High Definition Audio subsystem support
Security Chip
TPM (TCG V1.2 compliant)
*9
Card Slot PC Card Type I or Type II x 1 (3.3 V: 400 mA, 5 V: 400 mA)
ExpressCard ExpressCard/34 or ExpressCard/54 x 1
SD Memory Card
*10
x 1, Data transfer rate = 8 MB per second
*11
Smart Card
*12 x 1
RAM Module Slot 200-pin, 1.8 V, SO-DIMM, DDR2 SDRAM, PC2-5300 Compliant
Interface USB port (4-pin, USB 2.0) x 4, Serial Port (Dsub 9-pin male), Modem port (RJ-11), LAN port
(RJ-45), External display port (Mini Dsub 15-pin female), IEEE1394a Interface Connector (4-pin
× 1), Microphone Jack (Miniature jack, 3.5 DIA, Stereo), Headphone Jack (Miniature jack, 3.5
DIA, Impedance 32
Ω
, Output Power 4 mW × 2, Stereo)
Keyboard / Pointing Device 87 keys / Touch Pad
Power Supply AC adaptor or Battery pack
AC Adaptor
*13 Input: 100 V to 240 V AC, 50 Hz/60 Hz, Output: 15.6 V DC, 8.0 A
