145
7-4-2-2. Advanced Settings
Enable MAC Address Aging Out: Select to enable the MAC address aging out
function.
Age-Out Time: Enter the number of seconds that an inactive MAC address
remains in the switch's address table. The valid range is 300 to 765 seconds.
Default is 300 seconds.
Max Bridge Transmit Delay Bound: Limits the packets queuing time in the
switch. If enabled, the packets that exceed the time limit in the queue will be
dropped. This valid values are 1sec, 2 sec, 4 sec and off. Default is 1 second.
Enable Low Queue Delay Bound: Limits the low priority packets queuing time
in switch. If a low priority packet in the switch exceeds the Max Delay Time, it
will be sent. The valid range is 1to 255 ms.
NOTE: Make sure the “Max bridge transit delay bound control” is enabled
before enabling Delay Bound. The Enable Delay Bound only works under
“Max bridge transit delay bound control is enabled” situation.
Broadcast Storm Filter: The threshold is the percentage of the port's total
bandwidth used by broadcast traffic. To configure broadcast storm control, first
enable it and then set the upper threshold for each individual port. When
broadcast traffic for a port rises above the threshold set, broadcast storm
control becomes active. The valid threshold values are 5%, 10%, 15%, 20%,
25% and OFF.
