DC Electrical Characteristics
56F8322 Technical Data, Rev. 10.0
Freescale Semiconductor 105
Preliminary
10.2.1 Voltage Regulator Specifications
The 56F8322/56F8122 have two on-chip regulators. One supplies the PLL and has no external pins;
therefore, it has no external characteristics which must be guaranteed (other than proper operation of the
device). The second regulator supplies approximately 2.6V to the device’s core logic. This regulator
requires two external 2.2
µ F, or greater, capacitors for proper operation. Ceramic and tantalum capacitors
tend to provide better performance tolerances. The output voltage can be measured directly on the V
CAP
pins. The specifications for this regulator are shown in Table 10-6 .
Table 10-8 Current Consumption per Power Supply Pin (Typical)
On-Chip Regulator Disabled (OCR_DIS = High)
Mode I
DD_Core
I
DD_IO
1
1. No Output Switching
I
DD_ADC
I
DD_OSC_PLL
Test Conditions
RUN1_MAC 110mA 13
µ
A 25mA 2.5mA • 60MHz Device Clock
• All peripheral clocks are enabled
• Continuous MAC instructions with
fetches from Data RAM
• ADC powered on and clocked
Wait3 55mA 13
µ
A 35
µ
A 2.5mA • 60MHz Device Clock
• All peripheral clocks are enabled
• ADC powered off
Stop1 700
µ
A 13
µ
A 0
µ
A 360
µ
A
• 4MHz Device Clock
• All peripheral clocks are off
• Relaxation oscillator is on
• ADC powered off
• PLL powered off
Stop2 100
µ
A 13
µ
A 0
µ
A 145
µ
A • Relaxation oscillator is off
• All peripheral clocks are off
• ADC powered off
• PLL powered off
