EXTAL
(GPIOC0)
32 Input/
Schmitt
Input/
Output
Input
Input
External Crystal Oscillator Input — This input can be connected to
an 8MHz external crystal. If an external clock is used, XTAL must be
used as the input and EXTAL connected to V
SS
.
The input clock can be selected to provide the clock directly to the
core. This input clock can also be selected as the input clock for the
on-chip PLL.
Port C GPIO — This GPIO pin can be individually programmed as an
input or output pin.
After reset, the default state is an EXTAL input with pull-ups disabled.
XTAL
(GPIOC1)
33 Output
Schmitt
Input/
Output
Output
Input
Crystal Oscillator Output — This output connects the internal crystal
oscillator output to an external crystal.
If an external clock is used, XTAL must be used as the input and
EXTAL connected to V
SS
.
The input clock can be selected to provide the clock directly to the
core. This input clock can also be selected as the input clock for the
on-chip PLL.
Port C GPIO — This GPIO pin can be individually programmed as an
input or output pin.
After reset, the default state is an XTAL input with pull-ups disabled.
TCK 39 Schmitt
Input
Input, pulled
low internally
Test Clock Input — This input pin provides a gated clock to
synchronize the test logic and shift serial data to the JTAG/EOnCE
port. The pin is connected internally to a pull-down resistor. A Schmitt
trigger input is used for noise immunity.
TMS 40 Schmitt
Input
Input, pulled
high
internally
Test Mode Select Input — This input pin is used to sequence the
JTAG TAP controller’s state machine. It is sampled on the rising edge
of TCK and has an on-chip pull-up resistor.
TDI 41 Schmitt
Input
Input, pulled
high
internally
Test Data Input — This input pin provides a serial input data stream
to the JTAG/EOnCE port. It is sampled on the rising edge of TCK and
has an on-chip pull-up resistor.
TDO 42 Output Tri-stated Test Data Output — This tri-stateable output pin provides a serial
output data stream from the JTAG/EOnCE port. It is driven in the
shift-IR and shift-DR controller states, and changes on the falling edge
of TCK.
Table 2-2 Signal and Package Information for the 48-Pin LQFP
Signal Name Pin No. Type
State During
Reset
Signal Description
