Peripheral Memory Mapped Registers
56F8322 Technical Data, Rev. 10.0
Freescale Semiconductor 49
Preliminary
FCMB3_CONTROL $58 Message Buffer 3 Control / Status Register
FCMB3_ID_HIGH $59 Message Buffer 3 ID High Register
FCMB3_ID_LOW $5A Message Buffer 3 ID Low Register
FCMB3_DATA $5B Message Buffer 3 Data Register
FCMB3_DATA $5C Message Buffer 3 Data Register
FCMB3_DATA $5D Message Buffer 3 Data Register
FCMB3_DATA $5E Message Buffer 3 Data Register
Reserved
FCMB4_CONTROL $60 Message Buffer 4 Control / Status Register
FCMB4_ID_HIGH $61 Message Buffer 4 ID High Register
FCMB4_ID_LOW $62 Message Buffer 4 ID Low Register
FCMB4_DATA $63 Message Buffer 4 Data Register
FCMB4_DATA $64 Message Buffer 4 Data Register
FCMB4_DATA $65 Message Buffer 4 Data Register
FCMB4_DATA $66 Message Buffer 4 Data Register
Reserved
FCMB5_CONTROL $68 Message Buffer 5 Control / Status Register
FCMB5_ID_HIGH $69 Message Buffer 5 ID High Register
FCMB5_ID_LOW $6A Message Buffer 5 ID Low Register
FCMB5_DATA $6B Message Buffer 5 Data Register
FCMB5_DATA $6C Message Buffer 5 Data Register
FCMB5_DATA $6D Message Buffer 5 Data Register
FCMB5_DATA $6E Message Buffer 5 Data Register
Reserved
FCMB6_CONTROL $70 Message Buffer 6 Control / Status Register
FCMB6_ID_HIGH $71 Message Buffer 6 ID High Register
FCMB6_ID_LOW $72 Message Buffer 6 ID Low Register
FCMB6_DATA $73 Message Buffer 6 Data Register
FCMB6_DATA $74 Message Buffer 6 Data Register
FCMB6_DATA $75 Message Buffer 6 Data Register
FCMB6_DATA $76 Message Buffer 6 Data Register
Reserved
FCMB7_CONTROL $78 Message Buffer 7 Control / Status Register
FCMB7_ID_HIGH $79 Message Buffer 7 ID High Register
FCMB7_ID_LOW $7A Message Buffer 7 ID Low Register
FCMB7_DATA $7B Message Buffer 7 Data Register
Table 4-27 FlexCAN Registers Address Map (Continued)
(FC_BASE = $00 F800)
FlexCAN is NOT available in the 56F8122 device
Register Acronym Address Offset Register Description
