56F8322 Techncial Data, Rev. 10.0
38 Freescale Semiconductor
Preliminary
TMRA0_CMPLD2 $9 Comparator Load Register 2
TMRA0_COMSCR $A Comparator Status and Control Register
Reserved
TMRA1_CMP1 $10 Compare Register 1
TMRA1_CMP2 $11 Compare Register 2
TMRA1_CAP $12 Capture Register
TMRA1_LOAD $13 Load Register
TMRA1_HOLD $14 Hold Register
TMRA1_CNTR $15 Counter Register
TMRA1_CTRL $16 Control Register
TMRA1_SCR $17 Status and Control Register
TMRA1_CMPLD1 $18 Comparator Load Register 1
TMRA1_CMPLD2 $19 Comparator Load Register 2
TMRA1_COMSCR $1A Comparator Status and Control Register
Reserved
TMRA2_CMP1 $20 Compare Register 1
TMRA2_CMP2 $21 Compare Register 2
TMRA2_CAP $22 Capture Register
TMRA2_LOAD $23 Load Register
TMRA2_HOLD $24 Hold Register
TMRA2_CNTR $25 Counter Register
TMRA2_CTRL $26 Control Register
TMRA2_SCR $27 Status and Control Register
TMRA2_CMPLD1 $28 Comparator Load Register 1
TMRA2_CMPLD2 $29 Comparator Load Register 2
TMRA2_COMSCR $2A Comparator Status and Control Register
Reserved
TMRA3_CMP1 $30 Compare Register 1
TMRA3_CMP2 $31 Compare Register 2
TMRA3_CAP $32 Capture Register
TMRA3_LOAD $33 Load Register
TMRA3_HOLD $34 Hold Register
TMRA3_CNTR $35 Counter Register
TMRA3_CTRL $36 Control Register
TMRA3_SCR $37 Status and Control Register
TMRA3_CMPLD1 $38 Comparator Load Register 1
TMRA3_CMPLD2 $39 Comparator Load Register 2
TMRA3_COMSCR $3A Comparator Status and Control Register
Table 4-8 Quad Timer A Registers Address Map (Continued)
(TMRA_BASE = $00 F040)
Register Acronym Address Offset Register Description
