Text mode
Original mode

RESTRICTED USE ONLY

Fargo Electronics, Inc.

HDP 800 Series Card Printer/Encoders Service Manual (Rev. 5.0)

445

Entering the LCD Menu and Selecting an Option (continued)

Step Procedure

Use the scroll buttons to move up or down through the menu options, as shown
below. (Note: The brackets appear on either side of the active Menu option.)

Press the button below Select to choose an option. Choose from these five
categories: Print Test Image, Setup Printer, Show Error Count, Show Card
Count and System Upgrade.

Softkey Buttons

Scroll Buttons

Continued on the next page
