HDP 800 Series Card Printer/Encoders Service Manual (Rev. 5.0)
156
Attaching the Card Lamination Module (continued)
Step Procedure
7
Remove the one (1) screw which fastens the Card Output Bin to the Baseplate
and lift the bin up and off of the Printer.
Continued on the next page
