Point-to-Point Protocol (PPP)
procedure for configuring, 4-7
used with SNMP system, 1-2, 2-3, 2-4, 4-5, F-1
PORT (1– 2) interface
configuration options, C-6
failure message, 5-2
front panel LED indications, 3-4
functional description, 1-4, 2-1
managed by SNMP, E-1
physical description, 1-3
pin assignments, D-8
technical specifications, B-2
Port Use, 10BaseT, 4-3
power input
cabling example, 2-5
connector, 1-3, 1-4
consumption, B-1
requirement, B-1
troubleshooting, 5-15
power module, 1-4, B-1
power-up self-test
displaying results, 5-1
front panel indications, 2-6, 3-2
troubleshooting, 5-15
problem determination. See troubleshooting
protocol, link layer, 4-4, 4-7
Q
QRSS Test, 5-26
R
rate
communications port, C-18
external clock, C-16
synchronous data port, C-13
rear panel
connectors. See connectors, rear panel
physical description, 1-3
recover, asynchronous terminal operation, 3-6
remote loopback, 5-19
repeater loopback (RLB), 5-23
reset
asynchronous terminal operation, 3-6
front panel indications, 2-6
router applications, 2-1, 2-2
RS-449 interface, D-10
S
self-test
displaying results, 5-1
front panel indications, 2-6, 3-2
troubleshooting, 5-15
Send Ones configuration option, C-4, C-8
serial crossover cable, D-7
Serial Line Internet Protocol (SLIP)
procedure for configuring, 4-7
used with SNMP system, 1-2, 2-3, 4-5, F-1
SES (Severely Errored Seconds) report, 5-6
SNMP (Simple Network Management Protocol)
agent, 1-2
configuration options
examples of use, 4-4
option table, C-26
option worksheet, C-42
connection examples, 2-3, 2-5, F-1
database, 1-2
IP addressing, F-1
manager, 1-2
MIBs
functional description, E-1
list of objects, E-1– E-24
objects, 1-2
principles of operation, 1-2
traps, functional description, 1-2, 5-13
specifications, environmental, B-1, B-2
statistics
Ethernet, 5-8
performance, 5-5
Status branch
Ethernet statistics, 5-8
IP Routing Table, 5-10
status messages. See messages, status
straps. See configuration options
subnet, 4-4, C-26, C-27, F-2
subnet mask, 10BaseT port, C-23
synchronous data port. See PORT (1–2) interface
