10baset connector – HP 3162 User Manual
Page 144
Pin Assignments
D-4
3162-A2-GB20-40
August 2000
10BaseT Connector
Use a standard 10BaseT cable to connect the DSU to an Ethernet LAN. A cable
is provided with the DSU.
The following table defines the pinouts for the 10BaseT port. It is an 8-pin,
unkeyed jack.
Use
Pin #
Transmitted Data +
1
Transmitted Data –
2
Received Data +
3
NC
4
NC
5
Received Data –
6
NC
7
NC
8
NC = Not connected (unused).
