Technobeam
®
User Manual Menu Options 3-23
hours or fixture hours. The procedures below are listed in the order
that they appear on the menu map.
Viewing the Logic Board Temperature (TEMP)
To view the current logic board temperatures:
1. Press and hold the
2. Using the and arrow buttons, scroll to the “INFO” menu
and press the button to select the “INFO” menu.
3. Using the and arrow buttons, scroll to the “TEMP” option.
(This will be the first menu displayed.) Press the button to
select the “TEMP” option.
4. The LED will display the temperature of the fixture’s logic board in
degrees centigrade.
The maximum temperature reading for the logic board is 76° C. If this
maximum temperature is exceeded, the fixture’s lamp, LAD, and
motors will shut down and the LED panel will display “OVER TEMP.”
Viewing the Current Lamp Hours (L/HR)
To view the number of hours the lamp has been on since this option
was reset:
1. Press and hold the
2. Using the and arrow buttons, scroll to the “INFO” menu
and press the button to select the “INFO” menu.
3. Using the and arrow buttons, scroll to the “L/HR” option
and press the button to select the “L/HR” option. The LED will
display the number of hours the lamp has been on since this option
was reset.
Viewing the Current Fixture Hours (F/HR)
To view the number of hours the fixture has been on since this option
was reset:
1. Press and hold the
2. Using the and arrow buttons, scroll to the “INFO” menu
and press the button to select the “INFO” menu.
3. Using the and arrow buttons, scroll to the “F/HR” option
and press the button to select the “F/HR” option. The LED will
display the number of hours the fixture has been on since this option
was reset.
