Technobeam
®
User Manual Creating a Scene 4-7
Selecting a Color Wheel Pause Time
1. Use the and arrow keys to navigate to the COL
construct.
2. Press , then use the and arrow keys to select a
pause time (the higher the value, the longer the pause time).
3. Press to accept your selection.
Selecting Effects Constructs
1. Use the and arrow keys to navigate to the FX construct.
2. Press , then use the and arrow keys to select any
effects position other than FX 1 (open).
3. Press , then use the and arrow keys to navigate
to the FXR construct.
4. Press , then use the and arrow keys to select
either a forward or reverse rotation speed.
5. Press to save your settings.
Refocusing the Fixture
If you selected the suggested constructs, you should now see a litho
pattern being changed by a rotating effect and random color changes.
This section shows how you can use the fixture’s superior optics to
refocus the image.
1. Use the and arrow keys to navigate to the FCUS
construct.
2. Press , then use the and arrow keys to change
the focus. You can focus on the effects wheel, the litho wheel, the
color wheel or anywhere in between.
3. Press when you are done.
Setting a Delay Time
The DLAY construct determines the length of time scene 1 “plays”
before the next scene begins.
1. Use the and arrow keys to navigate to the DLAY
construct.
2. Press , then use the and arrow keys to select a
value of 3.0. This means that scene 1 will “play” for 3 seconds before
moving on to scene 2. (You will not see the effect of the DLAY
construct until you play back your programmed scenes.)
