3-20 Menu Options Technobeam
®
User Manual
Test Menu (TEST)
The Test menu allows you to manually home the fixture, turn the lamp
on or off, store new boot code information, perform fixture self tests,
and place the fixture in setup mode. If you are experiencing problems
that you suspect are mechanical, performing fixture self tests will help
to determine where the problem originates. The procedures below are
listed in the order that they appear on the menu map.
Note To see the effects of the self tests, the lamp must be on.
If the lamp is off when you run the self test, the LED will
display “STRK” to indicate that the lamp is not struck,
and the fixture will attempt to strike the lamp
automatically.
Homing the Fixture (HOME)
This menu item allows you to manually home the fixture. If you want
to remotely home the fixture (using a DMX controller), use the control
channel (DMX channel 18) (see Table 1 on page A-3 or Table 2 on page
A-8).
To manually home the fixture:
1. Press and hold the
2. Using the and arrow buttons, scroll to the “TEST” menu
and press the button to select the “TEST” menu.
3. Using the and arrow buttons, scroll to the “HOME”
option. (This will be the first option displayed.)
4. Press the button to select the “HOME” option. The LED will
alternately display “RST” and “HOME” while the fixture homes.
Turning the Lamp On or Off (LAMP)
You can manually turn the lamp on and off using either the TEST menu
or the SET menu.
To manually turn the lamp on or off via the TEST menu:
1. Press and hold the
2. Using the and arrow buttons, scroll to the “TEST” menu
and press the button to select the “TEST” menu.
3. Using the and arrow buttons, scroll to the “LAMP” menu
and press the button to select the “LAMP” menu.
4. Using the and arrow buttons, choose the “ON” option to
strike the lamp, the “OFF” option to extinguish the lamp.
