Page 99
Removal and Replacement Procedures
Maintenance and Service Guide
5–27
5.13 RTC Battery
✎
The RTC battery is included in the Miscellaneous Plastics Kit,
spare part number 344852-001.
1. Prepare the notebook for disassembly (Section 5.3) and
remove the following components:
❏
Optical drive (Section 5.7)
❏
Keyboard (Section 5.8)
❏
Keyboard cover (Section 5.9)
❏
Display assembly (Section 5.10)
❏
Top cover (Section 5.11)
❏
System board (Section 5.12)
2. Turn the system board upside down with the rear panel
facing you.
3. Remove the RTC battery from the socket.
Removing the RTC Battery
Reverse the above procedure to install the RTC battery.
333621-001.book Page 27 Wednesday, September 17, 2003 12:24 PM
