9 keyboard cover, 9 keyboard cover –16 – HP PAVILLION ZD7000 User Manual
Page 88
5–16
Maintenance and Service Guide
Removal and Replacement Procedures
5.9 Keyboard Cover
✎
The keyboard cover is included in the Miscellaneous Plastics Kit,
spare part number 344852-001.
1. Prepare the notebook for disassembly (Section 5.3).
2. Remove the keyboard (Section 5.8).
3. Turn the notebook upside down with the rear panel
facing you.
4. Remove the four PM2.5×8.0 screws 1 that secure the
keyboard cover to the notebook.
5. Remove the two PM2.5×8.0 screws 2 that secure the
keyboard cover to the notebook through the rear panel.
Removing the Keyboard Cover Screws
333621-001.book Page 16 Wednesday, September 17, 2003 12:24 PM
