Removal and Replacement Procedures
Maintenance and Service Guide 5–35
2. Disconnect the SD Card slot/infrared module cable 1 from
the LIF connector on the module.
✎
The SD Card slot/infrared module cable is included with the
SD Card slot/infrared module. It is also included in the
Miscellaneous Cable Kit, spare part number 344851-001.
3. Remove the three PM2.5×8.0 screws 2 that secure the
module to the notebook.
4. Remove the module bezel 3.
✎
The SD Card slot/infrared module bezel is included in the
Miscellaneous Plastics Kit, spare part number 344852-001.
5. Remove the module 4.
Removing the SD Card Slot/Infrared Module
Reverse the above procedure to install the SD Card slot/infrared
module.
