HP PAVILLION ZD7000 User Manual
Page 93
Removal and Replacement Procedures
Maintenance and Service Guide
5–21
4. Turn the notebook right-side up with the front facing you.
5. Remove the three PM2.5×8.0 screws 1 that secure the top
cover to the notebook.
6. Remove the two slotted M1.5×10.0 shoulder screws 2 that
secure the top cover to the notebook on each side of the
docking connector.
Removing the Top Cover Screws (continued)
333621-001.book Page 21 Wednesday, September 17, 2003 12:24 PM
