5–12 Maintenance and Service Guide
Removal and Replacement Procedures
5.8 Keyboard
1. Prepare the notebook for disassembly (Section 5.3).
2. Remove the memory expansion/Mini PCI compartment cover
(Section 5.5).
3. Turn the notebook upside down with the rear panel
facing you.
4. Loosen the eight PM2.5×5.0 screws 1 that secure the fan
cover to the notebook.
5. Remove the fan cover 2.
✎
The fan cover is included in the Miscellaneous Plastics Kit,
spare part number 344852-001.
Removing the Fan Cover
Spare Part Number Information
France
French Canada
Germany
Italy 344898-051
344898-121
344898-041
344898-061 Spain
Switzerland
United Kingdom
United States and
Canada
344898-071
344898-111
344898-031
344898-001
