5–18 Maintenance and Service Guide
Removal and Replacement Procedures
5.10 Display Assembly
1. Prepare the notebook for disassembly (Section 5.3).
2. Remove the keyboard (Section 5.8).
3. Remove the keyboard cover (Section 5.9).
4. Disconnect the display cable 1 and remove it from the
retaining clip 2 in the top cover.
5. Remove the two antenna cables from the hole and routing
channel in the top cover 3.
6. Remove the two PM2.5×8.0 screws 4 that secure the display
assembly to the notebook.
Removing the Display Assembly Screws
Spare Part Number Information
17.0-inch, WXGA
15.4-inch, WXGA 344894-001
344893-001
