5–8 Maintenance and Service Guide
Removal and Replacement Procedures
5.5 Memory Expansion Board
1. Prepare the notebook for disassembly (refer to Section 5.3).
2. Turn the notebook upside down with the rear panel
facing you.
3. Loosen the two PM2.5×4.0 screws 1 that secure the memory
expansion/Mini PCI compartment cover to the notebook.
4. Slide the cover forward 2, then lift the cover up 3.
5. Remove the cover.
✎
The memory expansion/Mini PCI compartment cover is included
in the Miscellaneous Plastics Kit, spare part number 344852-001.
Removing the Memory Expansion/Mini PCI Compartment Cover
Spare Part Number Information
1024-MB DDR, 333-MHz
512-MB DDR, 333-MHz
256-MB DDR, 333-MHz 324702-001
324701-001
324700-001
