Removal and Replacement Procedures
Maintenance and Service Guide 5–3
5.2 Disassembly Sequence Chart
Use the chart below to determine the section number to be
referenced when removing notebook components.
Disassembly Sequence Chart
Section Description
# of Screws
Removed
5.3 Preparing the notebook for disassembly
Battery pack
Hard drive 0
4 loosened
5.4 Notebook feet 0
5.5 Memory expansion board 2 loosened
5.6 Mini PCI communications board 2 loosened
5.7 Optical drive 2
5.8 Keyboard 8 loosened on fan
cover,
2 removed for keyboard
5.9 Keyboard cover 6
5.10 Display assembly 4
5.11 Top cover 13
5.12 System board 5 screws,
4 standoffs
5.13 RTC battery 0
5.14 Heat sink
Fans 4 loosened
6 removed
5.15 Processor 0
5.16 SD Card slot/infrared module 3
5.17 Speakers 3
