Working with Media
Take Up Reel loading

3-20

Take Up Reel loading

To start this procedure you need to have a roll of media installed into the printer see
page 3-33, Installing a New Roll into the Printer and Loading Roll Media 3-13.

CAUTION

Using Back-lit media with a separate slip sheet is not recommended for use with
the Take Up Reel.

1 Move the leading edge of the media to half way down the Core Tube. To move the

media down use the

↓ key as shown below. If the media has gone too far (i.e. passed

the Core tube) use the

↑ key to move the media back up.

NOTE:The Back Media/Forward Media display has a time-out of ten minutes. To
return to this display go to Utilities/Move Media.

C4704016

Back Media --------->

Forward Media ---->

FULL MENUS

C472334C

FULL MENUS

Utilities

Move Media
