Working with Ink Systems

Removing and Storing Partially Used Ink Systems

4-27

7 Insert the printhead into the stall with the color dot that matches the color of the

printhead label.

NOTE

Each printhead is color keyed to the correct stall and will not fit in any other
position.

8 Press down lightly and push the printhead away from you (toward the back of the

cradle) until it “clicks” into place.

9 Repeat steps 7 and 8 for the three remaining color printheads in the Ink System.

10 Put the top cover onto the HP DesignJet CP Ink System Storage Container and raise

the two lock-arms to the locked position.

C6240003

C6240004
