Configuration
4/07
UDC2500 Universal Digital Controller Product Manual
79
Function Prompt
Lower Display
Selection or Range of Setting
Upper Display
English
Numeric
Code
English
Numeric
Code
Parameter
Definition
A1S1EV 1103
BEGIN
END
0
1
If Setpoint Programming is enabled and if
the Alarm Type is configured for Event
On/Off:
ALARM 1 SEGMENT EVENT 1—Select
whether you want the alarm type chosen in
prompt A1S1TYPE to alarm the beginning or
end of a segment in setpoint Ramp/Soak
programming.
BEGINNING OF SEGMENT
END OF SEGMENT
ATTENTION Alarms configured for events
will not operate on Setpoint Program
segments of zero length.
A1S2TY 1104
ALARM 1 SETPOINT 2 TYPE—Select what
you want Setpoint 2 of Alarm 1 to represent.
The selections are the same as A1S1TYPE.
A1S2VA 1105 Value in
engineering units
ALARM 1 SETPOINT 2 VALUE—This is the
value at which you want the alarm type
chosen in prompt A1S2TYPE to actuate.
The details are the same as A1S1 VAL.
A1S2HL
A1S2EV
1106
1106
HIGH
LOW
BEGIN
END
0
1
0
1
ALARM 1 SETPOINT 2 STATE—Same as
A1S1HL.
ALARM 1 SEGMENT EVENT 2—Same as
A1S1EV.
A2S1TY 1107
ALARM 2 SETPOINT 1 TYPE—Select what
you want Setpoint 1 of Alarm 2 to represent.
The selections are the same as A1S1TYPE.
ATTENTION Not applicable with Relay
Duplex unless using Dual Relay PWA.
A2S1VA 1108 Value in
engineering units
ALARM 2 SETPOINT 1 VALUE—This is the
value at which you want the alarm type
chosen in prompt A2S1TYPE to actuate.
The details are the same as A1S1 VAL.
