Input Calibration
136 UDC2500 Universal Digital Controller Product Manual 4/07
5 Input Calibration
WARNING—SHOCK HAZARD
INPUT CALIBRATION MAY REQUIRE ACCESS TO HAZARDOUS LIVE CIRCUITS, AND
SHOULD ONLY BE PERFORMED BY QUALIFIED SERVICE PERSONNEL. MORE THAN
ONE SWITCH MAY BE REQUIRED TO DE-ENERGIZE UNIT BEFORE CALIBRATION.
5.1 Overview
Introduction
This section describes the field calibration procedures for Input 1 and Input 2.
• All input actuations in every UDC2500 controller are fully factory-calibrated and are
ready for configuration by the user.
• Field Calibration can improve the accuracy of the Controller if necessary for a
particular application.
CAUTION
The field calibration will be lost if a change in input type configuration is implemented at a later
time. The original factory calibration data remains available for later use after a field calibration
is done. See subsection 0 if you want to restore factory calibration values.
What's in this section?
The following topics are covered in this section.
TOPIC See Page
5.1 Overview 136
5.2 Minimum and Maximum Range Values 137
5.3 Preliminary Information 139
5.4 Input #1 Set Up Wiring 140
5.5 Input #1 Calibration Procedure 144
5.6 Input #2 Set Up Wiring 146
5.7 Input #2 Calibration Procedure 147
5.8 Restore Factory Calibration 149
