Configuration
4/07 UDC2500 Universal Digital Controller Product Manual 33
3.2 Configuration Prompt Hierarchy
Table 3-2 Configuration Prompt Hierarchy
Set Up Group Function Prompts
TUNING PB or
GAIN
RATE T I MIN or
I RPM
MANRST PB 2 or
GAIN 2
RATE2T I2 MIN or
I2 RPM
CYC T1
or
CT1 X3
CYC2T2
or
CT2 X3
SECUR LOCK AUTOMA RN HLD SP SL
SPRAMP SPRAMP TI MIN FINLSP SPRATE EUHRUP EUHRDN SPPROG STRSEG
ENDSEG RPUNIT RECYCL SOKDEV PG END STATE ToBEGN PVSTRT
SGx RP* SGxSP* SGx TI* * x = 1 to 12. Program concludes after segment 12
ATUNE FUZZY TUNE DUPLEX AT ERR
ALGOR CTRALG TIMER PERIOD START L DISP RESET INCRMT
OUTALG OUTALG OUTRNG CRANGE RLY TYP
INPUT1 IN1TYP XMITR1 IN1 HI IN1 LO RATIO1 BIAS 1 FILTR1 BRNOUT
EMISS
INPUT2 IN2TYP XMITR2 IN2 HI IN2 LO RATIO2 BIAS 2 FILTR2
CONTRL PIDSET SW VAL LSP’S RSP SRC SP TRK PWR UP PWROUT SP Hi
SP Lo ACTION OUT Hi OUT Lo D BAND HYST FAILSF FSMODE
PBorGN MINRPM
OPTIONS AUXOUT 0 PCT 100 PCT CRANGE DIG IN1 DI1 CMB DIG IN2 DI2 CMB
COM ComADD ComSTA IRENAB BAUD SDENAB SHDTIM WS_FLT TXDLY
SDMODE SHD_SP UNITS CSRATO CSP_BI LOOPBK
ALARMS A1S1TY A1S1VA A1S1HL A1S1EV A1S2TY A1S2VA A1S2HL A1S2EV
A2S1TY A2S1VA A2S1HL A2S1EV A2S2TY A2S2VA A2S2HL A2S2EV
ALHYST ALARM1 BLOCK DIAGAL
DISPLY DECMAL UNITS FREQ LWRDSP LNGUAG TCDIAG
STATUS VERSON FAILSF TESTS
