Chapter 2
Indicators, switches, and displays
Operator panel
Operator panel
The operator panel is located on the top left side of the server and
contains the key switch panel, DVD-ROM drive, optional DAT tape
drive, and the LCD display. Figure 13 shows the location of the operator
panel and its components.
Figure 13
Operator panel
3/24/99
V25U102
TOC
DC ON
DC OFF
CONSOLE
ENABLE
CONSLOLE
SECURE
DVD-ROM drive
Key switch panel
LCD display
Optional DAT drive
