8 Chapter 1
Overview
V-Class Server Architecture
Figure 7 V2500/V2600 HyperPlane Crossbar Connections
Each ERAC has 16 ports, 4 send and 4 receive on each side, which may
operate simultaneously.
V2500/V2600 Cabinet Components
The key components within a V2500/V2600 server cabinet include:
• “Core Utilities Board” on page 9
• “Processors” on page 9
• “Memory” on page 9
• “Input/Output” on page 12
In Chapter 2, you can find details on the V2500/V2600 cabinet external
controls, such as the on/off key switch panel, and cabinet displays,
including the LCD and attention light.
