6-139

Configuring the Switch

Class of Service (CoS): Managing Bandwidth More Effectively

C

o

n

fig
u

rin

g

th
e

Sw

itc
h

Configuring Class of Service from the Console

CoS uses dynamic reconfiguration to configure your CoS choices. This means
that it is not necessary to reboot the switch after configuring CoS.

To access the CoS console screens, begin at the Main Menu and select the
following:

3. Switch Configuration . . .

5. Advanced Features . . .

7. Class of Service (CoS) Menu . . .

Figure 6-87. The Class of Service Menu

Select the priority option you want to configure for CoS. The following screens
show the options with notes on how to configure them.

This option appears only if VLAN
support is activated in the console
VLAN menu.
