HP 8000M - Manual (Page 199)

6-123
Configuring the Switch
Configuring and Monitoring Port Security
C
o
n
fig
u
rin
g
th
e
Sw
itc
h
Using the Switch Console To Configure Port Security
From the Main Menu, select:
3. Switch Configuration . . .
5. Advanced Features . . .
5. Port Security
Figure 6-78. Example of the Console Port Security Overview Screen
Figure 6-79. Example of the Default Security Configuration Screen for a Selected
Port
1. Select a port to configure.
2. Select Edit to display the security
configuration screen for the selected
port.
3. To configure authorized devices, use the
Space bar to select Static for the Learn Mode
parameter, then press
[>] to display the
Address Limit and Authorized Addresses
parameters.
