6-34
Configuring the Switch
Network Monitoring Port Features
C
o
n
fig
u
rin
g
th
e
Sw
itc
h
Network Monitoring Port Features
From the web browser interface and switch console you can designate a
port for monitoring traffic on one or more other ports or on a VLAN configured
on the switch. The switch monitors the network activity by copying all traffic
from the specified ports or VLAN to the designated monitoring port.
N o t e It is possible, when monitoring multiple ports in networks with high traffic
levels, to copy more traffic to a monitor port than the link can support. In this
situation, some packets may not be copied to the monitor port.
Configuring Port Monitoring from the Web Browser
Interface
Figure 6-22. Setting Up Port Monitoring on the Web Browser Interface
Do one of the following:
• If you want to monitor one port or several ports, click on the Monitor
Selected Ports button. (See figure 6-23, below.)
• If you want to monitor VLAN traffic, click on the Monitor 1 VLAN
button. (See figure 6-24, below.)
1. Click Here
2. Click Here
3. Select the port to use for the
Designated Monitoring Port
