Software-based Configuration and Control, cont’d
MLC 104 Plus Series • Software-based Configuration and Control 3-22
PRELIMINAR
Y
IR Drivers
This Web page lists IR driver files only and allows you to select a file to see and
execute the commands stored in it. This page is available only to those logged in as
an administrator.
N The MLC must first be configured with Global Configurator before this page can
be used.
An example for a specific IR driver is shown below.
Serial Devices (serial drivers)
Once the ports have been set up in the configuration program, each configured
serial port (projector/display control port and MLS port) is listed in this section of
the Control page menu.
Click on a port name to bring up a page that shows the available
commands for the device cabled to that port. See the sample
screen shot on the next page.
If you want to execute a command that is available in the driver (whether
associated with an MLC button or not) for a configured device, you can click on a
button or select an option from a pull-down menu to execute that command.
N You must use Microsoft Internet Explorer version 6.0 or higher with ActiveX
enabled in order to use the serial devices’ control pages.
