Reference Material, cont’d
MLC 104 Plus Series • Reference Material A-14
PRELIMINAR
Y
MLC 104 IP Plus AAP or MLC 104 IP Plus DV+
MLC 104 IP Plus AAP
MLC 104 IP Plus DV+
Cut-Out Template for Extron's
TEMPLATE IS NOT FULL SIZE.
4.50" (11.43 cm)
To install the MLC
104 IP Plus AAP/DV+
directly into furniture,
cut along this line.
8.23"
(20.9 cm)
2.8" (7.1 cm)
SURFACE CUT-OUT AREA
FOR FURNITURE MOUNT
7.1"
(18.0 cm)
Top Panel
Location of MLC 104 IP Plus
N The solid lines on the
templates define the
cut‑out area, not the
dashed line.
