5-35 MLC 104 Plus Series • Special Applications
PRELIMINAR
Y
How these commands are typed into the Global Configurator Email Manager:
WCN
|
is the
SIS command
to read the
MLC’s unit
name.
WCI
|
is the SIS
command to
read the MLC’s
IP address.
WCT
|
is the
SIS command
to read the date
and time.
2
1
3
Resulting e-mail that is sent out upon equipment disconnection:
recipient
results: unit name.
results: unit’s IP address.
results: date and time.
2
1
3
SSI use in an MLC’s Web page
Reference notes:
An __.shtml file can be uploaded to the MLC by using one of the following:
• the File Management tab of MLC’s factory embedded Web page (http://<unit’s
IP address >/nortxe_index.html)
• an SIS command (see “File streaming commands” in chapter 5) via Telnet or
HyperTerminal
• a Web browser by sending a Post command on port 80 followed by the delimited
data in the .shtml file
The following figure shows a “remote”
serial command that ...
