4-37 MLC 104 Plus Series • SIS Programming and Control
PRELIMINAR
Y
Command/response table for special function SIS commands, continued
Command ASCII
Command
(host to MLC)
Response
(MLC to host)
X? values
and additional descriptions
Emulate a button/switch press X?
*42# SwPrs*
X?] This command causes the
MLC to issue the commands
associated with a button press.
X?
= the number of the memory
block for the button/switch
for which you want to emulate
a press (1 - 128). See the
diagrams on the preceding two
pages.
Emulate a button/switch release X?
*43# SwRls*
X?] This makes the MLC issue the
commands associated with a
button release.
X?
= the button’s/switch’s
memory block number (1-128).
Emulate a button press-and-
release X?
*44 # SwCmd*
X?] The MLC issues the commands
associated with both the press
and the release of the specified
button.
X?
= the button’s/switch’s
memory block number (1-128).
Example: 25*44# SwCmd*25
]
Example: emulate pressing and releasing the volume up button on the remote
control or rotating the MLC’s front panel Volume knob clockwise.
Example: 9*44# SwCmd*9
]
Example: emulate pressing and releasing the first input button. Actions associated
with the button press are executed first, followed directly by actions associated
with the button release.
Button control
Set slave (auxiliary switcher)
map
24
X?
*3
Y?
# SlaveMap
Y?
*
X? ] This command associates
an MLC input button with a
specific input on a connected
switcher.
X?
is the actual input channel
(including inputs on an
auxiliary switcher) to select
when button
Y?
is pressed. The
values for these variables are
shown at left.
Default: X? = Y?
00 = input 0
01 = input 1
02 = input 2
...
98 = input 98
99 = input 99
1 = input button 1
2 = input button 2
3 = input button 3
4 = input button 4
X? Y? values values
Example: 6*34# SlaveMap4*6
] Map input 6 (an input on an
auxiliary switcher) to the MLC’s
input button 4. When button
4 is pressed, the A/V system
switches to input 6, and any
instructions (DVD or VCR
control commands, for example)
associated with input button 4
on the MLC are executed.
Query slave map setting 3 Y? # X? ]
