UPS Specifications
35
5.4.1 Input Rectifier
Battery
Unit
Rating
Nominal
Input
Current
Maximum
Input
Current
OCP
Device
Rating
Bolt
Size
Maximum Recommended Lug
(Thomas & Betts Part Number)
Compression
2-Hole;
3/8" bolt
Mechanical
2-Hole;
40 82 at 480VDC 98 at 400VDC 70 8M 54106 ADR21
60 122 at 480VDC 146 at 400VDC 110 8M 54107 ADR21
80 163 at 480VDC 195 at 400VDC 150 8M 54152-TB ADR21
100 204 at 480VDC 244 at 400VDC 175 8M 54157 ADR21
120 244 at 480VDC 293 at 400VDC 225 8M 54167 ADR50
1. Nominal (Nom) current is based on full rated output load.
2. Maximum (Max) current (125% of nominal) is short duration for battery recharge conditions.
3. UPS input and bypass cables must be run in separate conduit from output cables.
4. Nominal battery voltage is shown at 2.0 volts/cell per NEC 480-2.
5. OCPD = Overcurrent Protection Device. Recommended AC input and AC output overcurrent protection represents 125% of nominal full
load current (continuous) per NEC 215.
6. Minimum-sized grounding conductors to be per NEC 250-122. Parity-sized ground conductors are recommended. Neutral conductors to
be sized for full capacity per NEC 310-15 (b)(4). References are per NEC 1999.
7. Wiring requirements:
a. AC Input: 3-phase, 4-wire, plus ground output.
b. AC Output: 3-phase, 3- or 4-wire, plus ground
8. All wiring is to be in accordance with national and local electric codes.
Table 9 Rectifier input power
Rated Power kVA 40 60 80 100 120
Rated Voltage, VAC 480
Supply 3-phase, 3-wire plus ground
Input Voltage Tolerance, VAC
(without derating)
384-552
Frequency, Hz 57-66
Power Factor > 0.99 at full load; >0.98 at half load
Harmonic Current Less than 3% at full rated UPS output load
See Table 8 for current ratings.
Overload capacity of input current:
100% Imax 125% Imax 150% load, less than 200msec
Table 10 Input voltage window with derating
Input Voltage Window
(L-L Voltage)
Percentage
of Nominal
Inverter Load,
Percentage
Charger Load,
Percentage
432VAC to 552VAC 90-115 100% 100%
431VAC to 384VAC 80-89 100% 30%
383VAC to 360VAC 75-79 100% 0%
359VAC to 288VAC 60-74 80% 0%
Table 11 Liebert approved replacement batteries
Battery Manufacturer Models Supplied
Enersys Yuasa HX205 — —
C&D Dynasty UPS12-100MR UPS12-150MR UPS12-210MR
Table 8 UPS terminal (continued)
