Magnum Energy MS-AEJ Series User Manual

Page 16

  • Text mode
  • Original mode
background image

© 2007 Magnum Energy Inc

Page 10

1 2 5 /8 "

1 2 "

4 7/8"

8 "

6 5/8"

2 "

4 7/8"

K e yh o le

slo ts (x4)

a n d

m o u n tin g

h o le s (x4)

a cce p t

u p to

9 /3 2 "

scre w/b o lt

1 3 3 /4 "

Figure 2-3, MS-AE Series Dimensions

Installation

Pages: 1 … 14 15 16 17 18 … 52
