Mounting the inverter
Page 16 Operating Instructions for Powador 3200-6600_EN
6 Mounting the inverter
DANGER
Risk of fatal injury from fire or explosions
Fire caused by flammable or explosive materials in the vicinity of the inverter can lead to serious
injuries.
› Do not mount the inverter in an area at risk of explosion or in the vicinity of highly flammable mate-
rials.
CAUTION
Risk of burns from hot housing components.
Coming into contact with the housing can cause burns.
› Mount the inverter so that it cannot be touched unintentionally.
Installation space
• As dry as possible, well-ventilated, with the waste heat dissipated away from the inverter,
• Unobstructed air circulation,
• When installing the unit in a control cabinet, provide forced ventilation so that the heat is sufficiently dissipated,
• Easily accessible from the front and sides,
• Protected from direct sunlight and moisture (rain and wind) in outdoor areas,
• For easy operation, ensure during installation that the display is slightly below eye level.
Wall
• With sufficient load-bearing capacity
• Protected against high winds,
• Accessible for installation and maintenance,
• Made from heat-resistant material (up to 90 °C)
• Flame resistant,
• Minimum clearances to be observed during assembly: see Bild 11 and Bild 12 auf Seite 18.
CAUTION
Property damage due to gases that have an abrasive effect on surfaces when they come into
contact with
ambient humidity caused by weather conditions
The inverter housing can be severely damaged by gases (ammonia, sulphur, etc.) if it comes
into
contact with ambient humidity caused by weather conditions.
If the inverter is exposed to gases, it must be mounted so that it can be seen at all times.
› Perform regular visual inspections.
› Immediately remove any moisture from the housing.
› Take care to ensure sufficient ventilation of the inverter.
› Immediately remove dirt, especially on vents.
› Failure to observe these warnings may lead to inverter damage which is not covered by the KACO
new energy GmbH manufacturer warranty.
