Technical Data
Page 12 Operating Instructions for Powador 3200-6600_EN
4 Technical Data
4.1 Electrical Data
Input levels 3200 4200 4400
Max. recommended PV generator power [W] 3 200 4 200 4 400
DC MPP range from [V] to [V] 350 ... 600
Open circuit voltage [V] 800
Input current max / Isc PV [A] 8.6 11.5 12.5
Max. power per tracker [W] 3 200 4 200 4 400
Number of strings 3
Number of MPP trackers 1
Polarity safeguard Short-circuit diode
Output levels
Rated power [VA] 2 600 3 450 3 600
Grid voltage [V] 184 - 264
Rated current [A] 11.3 15 15.6
Making current [RMS (20ms)] [A] 9.73
maximum initial residual current [A]
measured as 60ms RMS value
12.36
Rated frequency [Hz] 50/60
cos phi 0.80 inductive ... 0.80 capacitive
Number of feed-in phases 1
Distortion factor [%] <3
General electrical data
Max. efficiency [%] 96.6 96.6 96.5
European efficiency [%] 95.8 95.8 95.9
Internal consumption: Night [W] / Standby [W] 0/11
Feed-in starts at [W] Approx. 35
Grid monitoring Country-specific
Circuit design self-commutated, transformerless
Protection class 1
Transformer unit no
Clock frequency [kHz] 17/9
CE conformity Yes
