486 Tool and technology database
7.
2 T
ool edit
or
HC Holder type:
 A1: Boring bar holder
 B1: Right-hand, short design
 B2: Left-hand, short design
 B3: Right-hand, short design, overhead
 B4: Left-hand, short design, overhead
 B5: Right-hand, long design
 B6: Left-hand, long design
 B7: Right-hand, long design, overhead
 B8: Left-hand, long design, overhead
 C1: Right-hand
 C2: Left-hand
 C3: Right-hand, overhead
 C4: Left-hand, overhead
 D1: Multicarrier
 A: Boring bar holder
 B: Drill holder with coolant supply
 C: Square, longitudinal
 D: Square, transverse
 E: Rear-face machining
 E1: U drill
 E2: Cylindrical shank holder
 E3: Collet chuck holder
 F: Drill holder MK (Morse taper)
 K: Drill chuck
 T1: Driven, axial
 T2: Driven, radial
 T3: Boring bar holder
 X5: Driven, axial
 X6: Driven, radial
MP Tool position in turret:
 0: –Z direction
 1: –X/–Z direction
 2: –X/+Z direction
 3: +Z direction
WH Height of holder
WB Height of holder
AT Holder type
