110 Machine mode of operation
3.9 Pr
ogr
am Run mode
Activate the additive compensation
Enter the number of the additive compensation
Press the Delete soft key—these compensation
values are deleted
Press the Delete all soft key—all compensation
values are deleted
Program execution in "dry run" mode
The dry run mode is used for fast program execution up to a point at
which machining is to resume. The prerequisites for a dry run are:
 The CNC PILOT must be prepared by the machine tool builder for
dry run. (The function is activated with a keylock switch or a key.)
 The Program Run mode must be activated.
In dry run, all feed paths (except thread cuts) are traversed at the rapid
rate. You can reduce the traversing speed with the feed rate override.
Do not use the dry run feature for anything other than "cutting air."
When dry run is activated, the spindle status or spindle speed is
"frozen." After deactivation of the dry run, the CNC PILOT returns to
the programmed feed rates and spindle speeds.
DELETING ADDITIVE COMPENSATION
 Entered values are added to the existing compensation
values and are effective immediately.
 The compensation values are saved in an internal table
and are available in any program.
 Delete all additive compensation values when you set
up the machine again.
Use the dry run feature only to "cut air."
