390 ICP programming
6.5 Editing ICP cont
ours
Changing the length of the contour element
Press Manipulate. The menu displays functions for
trimming, editing and deleting contours.
Menu item Edit ...
... Select the contour element.
Select the contour element to be edited.
Present the selected contour element for editing.
Make the changes.
Load the changes.
The contour or, if applicable, the possible solutions are displayed for
inspection. Changes in form elements and unresolved elements are
loaded immediately (original contour in yellow, changed contour in red
for comparison).
Load the desired solution.
