6.16 Loading existing contours
Integrating cycle contours in smart.Turn
ICP contours that you have created for cycle programs can be
loaded in smart.Turn. ICP converts the contours into G commands and
integrates them in the smart.Turn program. The contour is now part of
the smart.Turn program.
The ICP editor considers the type of contour. For example, you can
load a contour defined for the face only if you have selected the face
(C axis) in smart.Turn.
Activate the ICP editor.
Press the Contour list soft key. The ICP editor
opens the window "Selection of ICP contours."
Press the Next file type soft key until the cycle
contours are displayed (see file extension table at
right).
Select the file.
Load the selected file.
 Blank or finished part contour: Supplement or adapt the
contour, if necessary.
 C-axis contour: Complete the reference data.
Extension Group
*.gmi Turning contours
*.gmr Contours of workpiece blanks
*.gms Milling contours on face
*.gmm Milling contours on lateral surface
