Teach-in mode
4.4 T
u
rn
ing cy
cles
Type of machining for technology database access: Finishing
By setting the following optional parameters, you can define
additional contour elements:
A:Oblique cut at contour start
W:Oblique cut at contour end
R:Rounding
B1:Chamfer/Rounding at contour start
B2:Chamfer/Rounding at contour end
WS:Angle of the chamfer at the contour starting point (not yet
implemented)
WE:Angle of the chamfer at the contour end point (not yet
implemented)
Cycle run
1
Move in transverse direction from the starting point to the contour
starting point X1, Z1
2
Finish contour area from contour starting point X1, Z1 to end
point X2, Z2,
taking optional contour elements into account
3
Move to the tool change position according to the G14 setting
MFE
M at end: M function that is executed at the end of the
machining step
WP
Displays which workpiece spindle is used to process the
cycle (machine-dependent)
Main drive
Opposing spindle for rear-face machining
