April 27, 2006 NewsBrowse Installation and Configuration Guide 165
Encoder stand-alone stage
For this configuration stage you configure and test one single-channel encoder, one
NAS, and one Profile XP server to work together.
The portion of the NewsBrowse system configured and tested in this stage is
illustrated by the following diagram.
Refer to “System diagram - Profile XP or Open SAN storage” on page 13 for a view
of the entire NewsBrowse system.
To do the basic configuration and testing of a single-channel encoder, do the
following:
1. “Configure ASK Location: Single-channel encoder” on page 166
2. “Configure Ingest Control: Single-channel encoder” on page 166
3. “Configure Proxy Asset (NAS): Single-channel encoder” on page 167
4. “Configure media server: Single-channel encoder” on page 168
5. “Configure MPEG encoder: Single-channel encoder” on page 169
6. “Test: Encoder stand-alone stage” on page 169
7. “Checklist: Encoder stand-alone stage” on page 171
Encoder stand-alone stage
Proxy
NAS
