Configuration - Jupiter System
Serial Protocol Table Entries
When a JEP-100 is connected to a CM-4000 serial port (and operated in
Serial mode), the panel must be configured for "ESCP" protocol using the
Serial Protocol table. The Baud rate should be set at 115K. Panels normally
operated in LAN mode do not require a Serial Proto col table entry.
MPK Table Entries
Although the JEP-100 is not actually an MPK-type panel (it has an on-board
microprocessor and does not use the Message Per Key stroke protocol), the
MPK table is used for configuration purposes. An example is shown in
Figure 17 .
Figure 17. MPK table for system shown in Figure 16 .
Device Type - For the panels always operated in LAN mode, select type
"ES-LAN" on the pull-down menu. For the panels normally operated in
Serial mode, select type "Serial."
Expansion - Not used for JEP-100 (leave unchecked).
Password - Not used for JEP-100.
Board - Name of CM-4000 connected to this JEP-100. The source of this
name is the Jupiter Network Description table.
Port - For LAN panels: Not used. For serial panels: Number of CM-4000
port connected to this JEP-100.
Address - For the panels always operated in LAN mode: enter the panel
address from 1 to 64; must be unique for panels associated with the same
CM-4000. For the panels normally operated in Serial mode: enter the panel
address from 1 to 16; must be unique for panels shar ing the same CM-4000
serial port.
JEP-100 panels are normally shipped with a panel address of "01." Modifi-
cation of this address was discussed on
page 30 .
This number is referred to as the "Device Number" on the IP configuration
page and "ID" within the JEP-100 MENU system.
