JEP-100 — Installation and Operating Manual 35
Configuration - Jupiter System
MPK Table Entries
Although the JEP is not actually an MPK-type panel (it has an on-board
microprocessor and does not use the Message Per Keystroke protocol), the
MPK table is used for configuration purposes. An ex ample is shown in
Figure 13.
Figure 13. MPK Devices table corresponding to system shown in Figure 12
MPK Devices - This column is used to create a name, up to eight characters
in length, for each JEP-100. This name must be unique system-wide.
Type - Select type "ES-LAN" on the pull-down menu.
Expansion - Not used for JEP-100 (leave unchecked).
Password - Not used for JEP-100.
Board - Name of CM-4000 associated with this JEP-100. The source of this
name is the Network Description table.
Port - Not used for LAN-only installation.
Address - Panel address from 01 to 64. Must be unique for panels associ-
ated with the same CM-4000.
JEP-100 panels are normally shipped with a panel address of "01." Modifi-
cation of this address was discussed on
page 30 .
This number is referred to as the "Device Number" on the IP configuration
page and "ID" within the JEP-100 MENU system .
Input Set - Name of CP Input Set to be assigned to this panel. The usu al
practice is to have one CP Input Set, containing the names of all in puts,
apply to all panels. However, special CP Input Sets could be created which
list only selected inputs; such a set could be used to prevent certain panels
from selecting specific inputs.
In Panel - This column is not used for JEP-100 panels.
Out Set - Output Set name. If the entry is an actual CP Output Set, then the
control panel will be able to control all the outputs listed in that Set.
Depending on the con tents of the set, this would allow for full-matrix or
multi-bus control.
JEP1 ES LAN 01
JEP2 ES LAN 02
1
MPK Devices
MPK
Expansion
Pass
Board
CM1
Port Address Input Sets Output Sets Level Set Overide Set Sequence Set
2 CM1 KXYZ INP KXYZ OUT KXYZ LEV
Devices word In Panel Out Panel
JEP64 ES LAN 64 64 CM1 KXYZ INP KXYZ OUT KXYZ LEV
KXYZ INP KXYZ OUT K KXYZ LEV
Type
Device
