Grass Valley JEP-100 v.1.2.0 User Manual
Page 23
JEP-100 — Installation and Operating Manual
21
Hardware Installation - Jupiter System
Figure 4. LAN + Serial system connections
Serial bus
CM-4000 System Controller
Serial
Ports
100baseT Jupiter LAN
16 JEP-100s per
serial bus maximum
to Jupiter
File Server
IP switch
64 LAN-operated
JEP-100s per CM
maximum
8536_10
Serial data cable (see
LAN (Cat 5 Ethernet) cable.
Max. recommended length per
seqment = 100 meters (329 ft)
Temporary LAN connection for
software upgrade
